Commonly used bag filters are as follows:
| specification | Clamp | bag type | Filter area | flow | Inlet and outlet flange | Wall thickness（mm） |
| Flange | ||||||
| Φ167×410 | Clamp | 4#bag | 0.13 | 12T | 25 | 1.5 |
| Flange | ||||||
| Φ167×810 | Clamp | 3#bag | 0.26 | 15T | 25 | 1.5 |
| Flange | ||||||
| Φ219×410 | Clamp | 1#bag | 0.23 | 20T | 50 | 1.5 |
| Flange | ||||||
| Φ219×810 | Clamp | 2#bag | 0.46 | 30-40T | 65 | 1.5 |
| Flange | ||||||
| Φ400×1300 | 2 bag type | 2#bag | 1.0 | 60-80T | 80 | 2 |
| Φ500×1500 | 3bag type | 2#bag | 1.38 | 90T | 100 | 3 |
| Φ500×1800 | 3bag type | 2#bag | 1.8 | 90T | 100 | 3 |
| Φ550×1300 | 4bag type | 2#bag | 1.8 | 120T | 100 | 3 |
| Φ600×1500 | 4bag type | 2#bag | 2.0 | 120T | 100 | 3 |
| Φ650×1500 | 5bag type | 2#bag | 2.2 | 150-160T | 125 | 3 |
| Φ750×1500 | 7bag type | 2#bag | 3.2 | 200T | 150 | 3 |
| Φ850×1500 | 9bag type | 2#bag | 4.12 | 240T | 175 | 3 |
| Φ900*2000 | 10bag type | 2#bag | 4.6 | 300 | 200 | 4 |
| Φ1000*2000 | 12bag type | 2#bag | 5.52 | 360 | 200 | 4 |
